Overview

This transceiver is a high-performance, cost-effective BiDi module with a simplex LC optical interface. It adopts standard AC-coupled CML for high-speed signals and LVTTL control & monitoring signals. It integrates a WDM filter; the receiver uses a PIN photodiode, and the transmitter is equipped with an FP laser. A link budget up to 5 dB enables this module to be used for 1000BASE Ethernet 3km single-fiber transmission.

Features

Ø  Up to 1.25 Gb/s Data Links

Ø  Hot-pluggable

Ø  BiDi simplex LC connector

Ø  Up to 3km on 9/125μm SMF

Ø  Single +3.3V Power Supply

Ø  Typical power consumption < 1 W

Ø  Maximum power consumption < 1.5 W

Ø  Industrial /Extended/ Commercial operating temperature range: -20°C to 70°C/-5°C to 70°C/-0°C to 70°C Version available

Ø  ROHS compliant and Lead Free

SFP Single-mode Single Fiber, 1310nm1550nm, 3km.pdf
